VEGAS WIRE GUARD T8

VEGAS WIRE GUARD DIFFUSER T8

INTENDED USE

This generation of linear direct fluorescent bare channel or batten fitting gives a new compact, low-profile design offering our customers unique product design which improve the overall installation process and appearance while reducing cost. Making it the most versatile solution for commercial, retail, manufacturing, warehouse, and cove and display applications. Designed to accommodate a wide variety of T8 lamp length.

CONSTRUCTION

Compact designed channel and cover are formed from high quality cold-rolled steel. Locking cover tracks bolsters strength of the overall fitting construction. High-gloss, baked white enamel finish. Wireguard with end caps.




DIMENSION OF FITTING

Wattage L
mm
W
mm
W1
mm
H
mm
H1
mm
1X20W 620 52 66 40 100
1X40W 1230 52 66 40 100
2X20W 620 52 135 40 100
2X40W 1230 52 135 40 100
